Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v
Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v
Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v
Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v
Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v
Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v
Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v
Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v

Low-profile design 150W indoor power supply comply with the world lighting equipment safety standards ac180-264v


Input

AC180-264V, 50/60Hz

Output

DC 12V 12.5A

DC 24V 6.25A 150W

Warranty

3Years

OEM

YES

Housing

Aluminum Housing

Working Temperature

-20~40°C

Protections

Short Circuit, Over Load, Over Voltage



Type

Constant Voltage, Single Output.



High Light

Built in active PFC Function: PF>0.97, THD<20%,

New topology LLC: high energy-efficient

Typic honeycomb shaped vents: for quick heat dissipation;

Long lifespan electrolytic capacitors: ensures the product lifespan

Low-profile design

LED indicator for power on

100% full load aging test before delivery ensuring 100% pass rate

Protections for safety: short circuit, over voltage, over load protections;

Certifications: CCC, CE, FCC certification



Product Details

Model Number

HX-150HF-12/24

LeadTime

Within 48 Hours: for regular stock models

Brand Name

WHOOSH / OEM

1-2 weeks: for OEM orders

Place of Origin

Hunan,China

Warranty

3 Years

MOQ

100PCS/Model

Sample Policy

Free samples 1-3PCS/Model

Customized Cost

Customized sticker/printing for free; Customized boxes for free >1000pcs each;

Payment Terms

T/T, Western Union,Money Gram

Supply Ability

22,000pcsper day

Aftersales

< 0.3% according to statistics collected;

Replacement against defective products pictures or more application details if needed

Ports support

Guangzhou, Shenzhen, Shanghai, Ningbo, Yi Wu, other mainland ports

Price

With detailed inquiry, Accurate quotation can be emailed within 24 hours;
Inquiry to: whooshpower@gmail.com



Product Description
Product Specification
1) Sepcifications

Model

Size/mm

Input

Output

Output Current

Warranty

HX-150HF-12

159*97*30

AC 180-264v

DC12V

12.5A

3 Years

HX-150HF-24

DC24V

6.25 A

2) Input Characteristics

Input Voltage: AC 200-264V

Input Frequency: 50/60Hz

Input Current: 1.0A Max (full loaded at the lower limited of input voltage range)

Inrush Current:30AMax. Cold start at 240Vac input, with rated load and 25℃ ambient.

Ac Leakage Current:0.75mA Max. At 240Vac input

3) Output Characteristics

1. Output Power

Voltage

Min. Load

Rated Load

Peak@10mS

Output power

12V

0A

12.5A

180W

150W

24V

0A

6.25 A

180W

150W



2. Line Regulation

Voltage

Min. Load

Rated Load

Line Regulation

Load Regulation

12V

0A

12.5A

±3%

±5%

24V

0A

6.25 A

±3%

±5%



3. Ripple and Noise

Under nominal voltage and nominal load,the ripple and noise are as follows when measure with Max.Bandwidth of 20MHz and Parallel 47uF/0.1uF,crossed connected at testing point.

Voltage

Ripple and Noise(Max.)

12V

200mV p-p

24V

300mV p-p

4. Turn on delay time: 2Second Max.at 220Vac input and output Max.load.

5. Rise time: 10mS Max.at 240Vac input and output Max load.

6. Efficiency: 12V 88%Min; 24V 90%Min, At 220Vac input voltage and full load calculation efficiency.

7. Overshoot: 10% Max. When power supply at turn or turn off.

4) Protection Functions:

1. Short circuit protection: auto recovered when short circuit faults remove.

2. Over current Protection: auto recovered when over current faults remove.

3. Over load protection: auto recovered when over current faults remove.

5)Test

Drop test, Salt Spray Test, Surge test, Ageing test, lightning test, Temperature Variation test etc.

6) Safety Requirement

EMC/EMI

1.Safety Standard:

Safety: Design by : GB19510.1-2009GB19510.4-2009

2.Insulation resistance:100MΩmin at 500V DC
7) EMI& EMCRequirement

Designed according to the following standards:

1. GB17743-2007

2. GB17625.1-2012

8Structurer

HX-HF Series Specification



Model No.

Size

Efficiency

Output current

PF

Output Volt

Input Volt

HX-60HF-12

104*82*30mm

80%

5.0A

0.9

12V DC

200240Vac

HX-60HF-24

104*82*30mm

83%

2.5A

0.9

24V DC

200240Vac

HX-100HF-12

159*97*30mm

88%

8.33A

0.9

12V DC

200240Vac

HX-100HF-24

159*97*30mm

90%

4.17A

0.9

24V DC

200240Vac

HX-150HF-12

159*97*30mm

88%

12.5A

0.9

12V DC

200240Vac

HX-150HF-24

159*97*30mm

90%

6.25A

0.9

24V DC

200240Vac

HX-200HF-12

159*97*30mm

88%

16.7A

0.9

12V DC

200240Vac

HX-200HF-24

159*97*30mm

90%

8.33A

0.9

24V DC

200240Vac

HX-250HF-12

215*115*31mm

85%

20.8A

0.9

12V DC

200240Vac

HX-250HF-24

215*115*31mm

88%

10.4A

0.9

24V DC

200240Vac

HX-300HF-12

215*115*31mm

85%

12.5A

0.9

12V DC

200240Vac

HX-300HF-24

215*115*31mm

88%

25.0A

0.9

24V DC

200240Vac

HX-350HF-12

215*115*31mm

85%

29.1A

0.9

12V DC

200240Vac

HX-350HF-24

215*115*31mm

88%

14.6A

0.9

24V DC

200240Vac

HX-400HF-12

215*115*31mm

85%

33.3A

0.9

12V DC

200240Vac

HX-400HF-24

215*115*31mm

88%

16.7A

0.9

24V DC

200240Vac



9) OEM



Customize label and Inner box

 10) Packing details Pack in a big brown carton outside and a box or a bubble bag per piece inside. (Or negotiate when order).





11)Shipping



12)Company Information



--We are on exhibitions!

Each year we have 3-4 domestic exhibitions (ISLE, SIGN CHINA, SHANGHAI LIGHT EXPO etc.) and 2-3 overseas exhibitions ( Asian, Middle East etc.)



--Honor & Certifications:



ISO9001:2015 (certified by SGS) Quality Management System, Korea KC certification, EU CB Certification, CE, ROHS, CCC, EMS, LVD, IP67 Waterproof Level Certifications etc.



FAQ

Q: Can I get samples?

A: Yes, 1pc is available if needed.



Q: What’s your MOQ?

A: Normally the MOQ for commercial order is 1 carton for each kind of product.

However, 1pc can be available to support for your trail order, welcome to inquiry.



Q: Is there any discount?

A: Of course. Price is based on your quantity. We are committed to supplying best price for every customer.



Q: How about delivery time?

A: 1-25days which depends on detail items and quantity.



Exporting port:Guangzhou, Shenzhen, Shanghai, Yiwu, Lianyungang, Tashkent, etc. Guangzhou is the nearest port.



After-sales service:

A strong factory since 2004 and 400 employees, top 5 biggest manufacturer in China to support the aftersales.

We will always behind you to support you with less than 1% natural defective rate.

Payment term:T/T, Western Union, PayPal, or negotiate when order.

Any needs, we are always here for you.
